Description
- 18,000rpm HSK-A63 Spindle with 80 ATC and 47HP
- 12 Pallet Palletech, Two level System with the ability for field expandability (2023 install)
- Smooth Ai Control, 19″ Screen with Smoothing Software
- High Speed Machining Software and Smooth Link
- SMC Plus Settings and Smooth Set & Inspect
- EIA/ISO Function, Simultaneous 5-axis and Tool Tip Point Control/Simultaneous 5-axis
- 5-axis Spline Interpolation and Fine Spline Interpolation
- 1000psi Spindle Through Coolant (T8) and Spindle Chiller
- LNS Turbo SF Compact Rear Exit Chip Conveyor Double belt for fine and large chips
- AI Thermal Shield and Cooled Ball Screws
- Auto Power On/off + Warmup
- Mazak’s Hybrid Roller Guide Ways
- RMP600 Radio Part Probe and GIS Supplied TS27R Probe Kit for tool setting & tool wear
- Workpiece Air Blast and Mist Collector
- Work Holding (3 jaw chuck, 2x 5th axis vises, & 3 kurt vises) Plus 35 HSK holders
